Inline Type Joint Box Fiber Optic Joint Enclosure 96 Core Fiber Optic Junction Box
Product Description
96 Core Optic Splice Joint Closure Horizontal Types 2 in 2 out are used to distribute, splice, and store the outdoor optical cables which enter and exit from the ends of the closure. There are two connection ways:direct connection and splitting connection. They are applicable to situations such as overhead, man-well of pipeline, embedded situation etc. Comparing with terminal box, the closure requires much stricter requirement of seal.
Features
1. The closure casing is made of quality engineering PP plastics, and of good performance of anti-erosion against acid and alkali salt, anti-aging, as well as smooth appearance and reliable mechanical structure.
2. The mechanical structure is reliable and has the performance of resisting wild environment and intensive climate changes and serious working environment. The protection grade reaches IP68.
3. The closure is of small volume, big capacity and convenient maintenance.The elastic rubber seal rings inside the closure are of good sealing and sweat-proof performance.
Application
1.Direct buried installation
2.Pole mounted installation
3.Wall mounted installation
4.Man hole and hand hole installation
5.FTTH access layer
Specification
| Model | TW-GJS(04)-1 |
| Type | Inline type |
| Number of Inlet/Outlet ports | 4 ports |
| Cable Diameter | 10-17mm |
| Maximum Capacity | 96 fibers; |
| Capacity per Splice Tray | 24Cores |
| Quantity of Splice Tray | 4pcs |
| Body Material | PC |
| Sealing Structure | Sticky cincture |
| Assembling method | Aerial, direct buried, pipelined, wall mounting, manhole |
| Dimension | 435(L)×190(W)×85(H)mm |
| Net Weight | 2.5~2.7KG |
| Temperature | -40℃~65℃ |
